Martin MAC Viper Profile

The MAC Viper Profile is a new breed of high-output profile luminaire with an exceptional feature set, superior light quality and a highly efficient optical system.

It outperforms all market-leading profiles in the 1200-watt range and is even an alternative to 1500-watt fixtures. The Viper Profile is not only brighter, it is also a faster and more compact solution. With its 1000-watt HID source, the Viper consumes less power, making it over 50% more efficient than its 1200-watt rivals.

26000 Lumens – Excellent light quality with a very flat and uniform field and 6000K colour temperature
1:4 zoom – Fast zoom with auto-linked focus
Large aperture front lens – The 140 mm front lens exceeds the size of any other fixture in this segment for just the right fat beam look

26000 Lumens – Excellent light quality with a very flat and uniform field and 6000K colour temperature
1:4 zoom – Fast zoom with auto-linked focus
Large aperture front lens – The 140 mm front lens exceeds the size of any other fixture in this segment for just the right fat beam look
2 x 5-slot rotating gobo wheels - All glass gobos with optimal focal separation for superior morphing effects
FX wheel – Patent-pending FX wheel provides an additional 4 fixed gobos and 135° animation effect
CMY – Vibrant colour mixing with a superior palette of colours including true reds, rich ambers, primary green and deep blues
8-slot colour wheel – Static colours and correction filters for added colour choice and bump effects
Linear CTO – Daylight to tungsten CCT control and expansion of the CMY palette
Dimmer and shutter - Combined dimmer/shutter system with intensity effects, instant blackout/open and smooth fades
Iris – Fast and tight iris with adjustable dynamic effects
Strobe – Diverse strobe effects using mechanical or electronic control or in combination
Soft frost – A light frost leaves gobo artwork visible with a beautiful soft edge. Includes a linear focus blurring option
4-facet prism – Real beam separation with rotation and index control for dynamic effects and accurate tiling

Physical
Length (Head)	566 mm (22.3 in.)
Width	472 mm (18.6 in.)
Width (Base)	335 mm (13.2 in.)
Height (head straight up)	731 mm (28.8 in.)
Height (maximum)	748 mm (29.5 in.)
Weight	37.2 kg (82.0 lbs.)
Dynamic Effects
Colour mixing	CMY, independently variable 0 - 100%
Colour temperature control	CTO, variable 6000 - 3200 K
Colour wheel	8 interchangeable dichroic filters + open, indexing, continuous rotation, random colour
Aerial wheel	5 interchangeable aerial effects + open, indexing, continuous rotation and shake
Breakup wheel	5 interchangeable texture/breakup gobos + open, indexing, continuous rotation and shake
FX wheel	Interchangeable static gobo and gobo animation effects
Prism	Interchangeable 4-facet rotating prism
Iris	0 - 100%, pulse effects
Frost	Frost filter
Mechanical dimmer/shutter	0 - 100% continuous dimming, variable & random strobe & pulse effects, instant open & blackout
Dimming options	Choice of four dimming curves
Focus	Range varies with zoom angle, from 2 m / 6 m to infinity (approx.)
Zoom-focus linking system	3-zone
Zoom	Motorised
Pan	540°
Tilt	268°
Position correction system	Absolute position monitoring
Control and Programming
DMX channels	26/34
Setting and addressing	Control panel with backlit graphic display and jog wheel or via DMX 16-bit control
DMX compliance	USITT DMX512-A
RDM compliance	ANSI/ESTA E1.20
Receiver	Opto-isolated RS-485
Firmware update	USB memory device or USB/DMX hardware interface over DMX link
Lamp
Type	1000 W short-arc discharge
Colour temperature	6000 K
CRI (Colour rendering index)	>85
Average lifetime	750 hours
Socket	PGJX36
Ballast	Electronic
Approved lamps	Osram Lok-it! 1000/PS Brilliant, Osram Lok-it! 1000W/PS VS1, Philips MSR Gold MiniFastFit 1000W
Optics
Zoom range	10-44° (1:4)
Output	26 000 lm
Service Utilities
Fixture identification	User-settable fixture ID number
Construction
Colour(s)	Black
Housing	UV-resistant fibre-reinforced composite
Reflector	Glass, cold light
Protection rating	IP20
Gobos
Size	E27 (Size E, max. image diameter 27 mm)
Approved material	Borosilicate 3.3 or better with dichroic or heavy matted aluminium coating (metal gobos not approved)
Outside diameter	37.5 mm +0/- 0.2 mm (1.5 in. +0/- 0.01 in.)
Maximum image diameter	27 mm (1.1 in.)
Maximum thickness	1.1 mm +/- 0.1 mm (0.1 in. +/- 0.01 in.)
Installation
Mounting points	Eight quarter-turn locking points
Orientation	Any
Minimum distance to illuminated surfaces	3.4 m (11.2 ft.)
Minimum distance to combustible materials	0.3 m (1.0 ft.)
Connections
AC power input	Neutrik PowerCon
DMX and RDM data in/out	5-pin locking XLR
USB memory devices	USB host socket
Electrical
AC power	120-240 V nominal, 50/60 Hz
Power supply unit	Auto-ranging electronic switch-mode
Typical half-cycle RMS inrush current	16.2 A
Typical Power and Current
120 V, 60 Hz	1225 W, 10.3 A, PF 0.999
208 V, 60 Hz	1190 W, 5.8 A, PF 0.996
230 V, 50 Hz	1186 W, 5.2 A, PF 0.994
240 V, 50 Hz	1194 W, 5.0 A, PF 0.993
Measurements made at nominal voltage.
Allow for a deviation of +/- 10%. PF = power factor
Thermal
Cooling	Filtered forced air (temperature-regulated, low noise)
Maximum ambient temperature (Ta max.)	40° C (104° F)
Minimum ambient temperature (Ta min.)	5° C (41° F)
Maximum surface temperature, steady state, at 40° C ambient	150° C (302° F)
Total heat dissipation (calculated, +/- 10% at 120 V, 60 Hz)	4180 BTU/hr
Approvals
EU safety	EN 60598-2-17 (EN 60598-1), EN 62471
EU EMC: ::EN 55015, EN 55103-1, EN 55103-2, EN 61547
US safety	UL 1573
US EMC	FCC Part 15 Class A
Canadian safety	CSA E598-2-17 (CSA E60598-1)
Canadian EMC	ICES-003 Class A
Australia/NZ	C-TICK N4241
